Product Summary

The SN74LS13N is a dual 4-input Positive-NAND Schmitt trigger. Each circuit function as a 4-input NAND gate, but because of the Schmitt action, it has different input threshold levels for positive and for negative going signals. The SN74LS13N is characterized for operation over the full military temperature range of 0℃ to 70℃.

Parametrics

SN74LS13N absolute maximum ratings: (1)Supply voltage, VCC: 7V; (2)Input voltage: 7V; (3)operating free-air temperature: 0℃ to 70℃; (4)Storage temperature range: -65℃ to 150℃.

Features

SN74LS13N features: (1) Operation from Very Slow Edges; (2) Improved Line-Receiving Characteristics; (3) High Noise Immunity.

Diagrams

SN74LS13N block diagram
