Product Summary

The MHC3225S102N is a High Current Chip Ferrite Bead. The applications of the MHC3225S102N include High current DC power lines, Circuits where a stable ground in unavailable.

Parametrics

MHC3225S102N absolute maximum ratings: (1)Operating temperature range: -55℃ to +125℃; (2)Storage temperature: -40℃ to +85℃, 70% RH Max; (3)Soldering method: Reflow or Wave Soldering; (4)Impedance(Ω)+/- 25%: 1000Ω; (5)Test Freq.(MHz): 50MHz; (6)DCR (Ω)(Max.): 0.090Ω; (7)Rated Current: 2000mA.

Features

MHC3225S102N features: (1)Combination of high frequency noise suppression with capability of handing high current; (2)The current rating up to 6 Amps with low DCR.

Diagrams

MHC3225S102N dimension
