Product Summary
The DS4E-M-12V is a highly sensitive 1500V FCC surge withstanding miniature relay. The applications of the DS4E-M-12V include Telecommunication equipment, Office equipment, Computer peripherals, Security equipment, and measuring instrumentation.
Parametrics
DS4E-M-12V absolute maximum ratings: (1) Arrangement: 1 Form C, 2 Form C, 4 Form C; (2) Initial contact resistance, max.(By voltage drop 6V DC 1A): 50mΩ; (3)Contact material: Gold-clad sliver; (4)Max. Switching power: 60W, 125VA; (5) Max. Switching voltage: 220V DC, 250V AC; (6) Max. Switching current: 2A DC, AC; (7) Max. Carrying current: 3A DC, AC.
Features
DS4E-M-12V features: (1)High sensitivity: 200mW pick-up power, 100mW pick-up power types available; (2)Latching types available; (3)High switching capacity: 60W, 125V A; (4)High breakdown voltage: 1500V FCC surge between open contacts, 1000V AC between open contacts; (5)DIP-1C type can be used with 14 pin IC socket, 2C type can be used with 16 pin IC socket, 4C type can be used with 2 sets of 14 pin IC sockets; (6)Gold-cap silver palladium types available for 2 Form C type; (7)Bifurcated contacts are standard.
Diagrams
 |
 DS4E-M-DC1.5V |
Panasonic Electric Works |
Low Signal Relays - PCB 4 Form C, 1.5VDC 4 Form C 400mW Type |
Data Sheet |
Negotiable |
|
||||
|
DS4E-M-DC12V |
Panasonic Electric Works |
Low Signal Relays - PCB 2A 12VDC 4PDT NON-LATCHING PCB |
Data Sheet |
Negotiable |
|
||||
|
DS4E-M-DC24V |
Panasonic Electric Works |
Low Signal Relays - PCB 2A 24VDC 4PDT NON-LATCHING PCB |
Data Sheet |
Negotiable |
|
||||
|
DS4E-M-DC3V |
Panasonic Electric Works |
Low Signal Relays - PCB 4 Form C, 3VDC 4 Form C 400mW Type |
Data Sheet |
Negotiable |
|
||||
|
DS4E-M-DC48V |
Panasonic Electric Works |
Low Signal Relays - PCB 2A 48VDC 4PDT NON-LATCHING PCB |
Data Sheet |
Negotiable |
|
||||
|
DS4E-M-DC5V |
Panasonic Electric Works |
Low Signal Relays - PCB 2A 5VDC 4PDT NON-LATCHING PCB |
Data Sheet |
Negotiable |
|
||||
