Product Summary

The 2SD2560 is a Silicon PNP Epitaxial Planar Transistor. The applications of the 2SD2560 include Audio, Series Regulator and General Purpose.

Parametrics

2SD2560 absolute maximum ratings: (1)VCEO: 150V; (2) VCBO: 150V; (3)VEBO: 5V; (4)IC: 15A; (5)IB: 1A; (6)PC: 130W @ TC=25℃; (7)Tj: 150℃; (8)Tstg: -55℃ to +150℃.

Features

2SD2560 features: (1)ICBO: 100max μA; (2)IEBO: 100max μA; (3)V(BR)CEO: 150min V; (4)hFE: 5000 min; (5)VCE(sat): 2.5max V; (6)VBE(sat): 3.0max V; (7)fT: 70typ MHz; (8)COB: 120typ pF.

Diagrams

2SD2560 dimension
