Product Summary
The 2SD92 is a transistor.
Parametrics
2SD92 absolute maximum ratings: (1)VCBO: 100V; (2)VCEO: 55V; (3)VEBO: 6V; (4)IC: 3A; (5)IB: 1A; (6)PC: 20W @ TA=25℃; (7)Tj: 150℃; (8)Tstg: -65℃ to +150℃.
Features
2SD92 features: (1) ICBO: 30uA 50V; (2) IEBO: 200uA; (3) VCEO: 55V @ IC=50mA; (4)hFE: 20min. 40Typ.; (5)VCE(sat): 1.0V max. 0.4V Typ.; (6)fab: 3.5Mhz Typ. 1.5MHz Min.
Diagrams
 |
