PYF08A

PYF08A, Versatile and Function-filled Miniature Power Relay, DIP, 100mΩ, 35g, 2,000VAC, 50/60Hz

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.00~6.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $3.00~6.00

PartNumber:: PYF08A

Brand:: Omron Electronics LLC - OMRON | Pack: DIP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. April's store

(Singapore)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-07-15

From Other Seller

Part Number:PYF08A
US $3.00 - 6.00
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
IRF3205

US $0.80 - 2.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The PYF08A is a Versatile and Function-filled Miniature Power Relay for Sequence Control and Power Switching Applications.

Parametrics

PYF08A absolute maximum ratings: (1) Contact resistance: 100mΩ max.; (2) Operate time: 20ms max.; (3) Release time: 20ms max.; (4) Max. operating frequency: Mechanical: 18,000 operations/hr; (5)Electrical: 1,800 operations/hr (under rated load); (6)Insulation resistance: 1,000MΩ min. (at 500 VDC); (7)Dielectric strength: 2,000 VAC, 50/60Hz for 1.0 min (1,000 VAC between contacts of same polarity); (8)Vibration resistance: Destruction: 10 to 55 to 10 Hz, 0.5 mm single amplitude (1.0 mm double amplitude); (9)Malfunction: 10 to 55 to 10 Hz, 0.5 mm single amplitude (1.0 mm double amplitude); (10)Shock resistance Destruction: 1,000 m/s2; (11)Malfunction: 200 m/s2; (12)Ambient temperature: Operating: –55℃ to 70℃ (with no icing); (13)Ambient humidity: Operating: 5% to 85%; (14)Weight: Approx. 35g.

Features

PYF08A features: (1)Models with lockable test buttons now available; (2)Many variations possible through a selection of operation indicators (mechanical and LED indicators), lockable test button, built-in diode and CR (surge suppression), bifurcated contacts, etc; (3)Arc barrier standard on 4-pole Relays; (4)Dielectric strength: 2,000 VAC (coil to contact); (5)Environment-friendly cadmium-free contacts; (6)Safety standard approvals obtained; (7)Wide range of Sockets (PY, PYF Series) and optional parts are available; (8)Max. Switching Current: 2-pole: 10 A, 4-pole: 5 A; (9) provided with nameplate.
