HC-55516

HC-55516, half duplex modulator/demodulator CMOS, DIP, 7V, 9 to 64kbps, 1.5mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $7.00~9.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $7.00~9.00

PartNumber:: HC-55516

Brand:: Harris Corporation - Harris | Pack: DIP | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. April's store

(Singapore)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-07-14

From Other Seller

Part Number:HC-55516
US $7.00 - 9.00
TDA7360

US $0.80 - 1.50 / Piece
(0) Remove
PIC16F917-I/P(PIC16F917-IP)

US $1.60 - 2.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The HC-55516 is a half duplex modulator/demodulator CMOS intergrated circuit used to convert voice signals into serial NRZ digital data and to reconvert that data into voice. The conversion is by delta-modulation, using the Continuously Variable Slope (CVSD) method of modulation/demodulation. The applications of the HC-55516 include Voice Transmission over Data Channels (Modems), Voice/Data Multiplexing (Pair Gain), Voice Encryption/Scrambling, Voicemail, and Audio Manipulations: Delay Lines, Time Compression, Echo Generation/Suppression, Special Effects, etc. Pagers/Satellites, Data Acquisition Systems, Voice I/O for Digital Systems and Speech Synthesis Requiring Small Size, Low Weight, and Ease of Reprogram ability, Related Literature: AN607, Delta Modulation for Voice Transmission.

Parametrics

HC-55516 absolute maximum ratings: (1)Voltage at Any Pin: GND -0.3V to VDD 0.3V; (2)Maximum VDD Voltage: 7.0V; (3)Junction Temperature: 175℃; (4)Operating VDD: 4.5V to 6.0V; (5)Transistor Count: 1897; (6)Die Dimensions: 147×82; (7)Substrate Potential: +VDD; (8) Process: BiMOSE.

Features

HC-55516 features: (1)All Digital; (2)Requires Few External Parts; (3)Low Power Drain: 1.5mW Typical From Single 4.5V To 6V Supply; (4)Time Constants Determined by Clock Frequency; No Calibration or Drift Problems: Automatic Offset Adjustment; (5)Half Duplex Operation Under Digital Control; (6)Filter Reset Under Digital Control; (7)Automatic Overload Recovery; (8)Automatic "Quiet" Pattern Generation; (9)AGC Control Signal Available.
